Description
6200-ZZ (6200ZZ) Deep Grooved Ball Bearing Shielded 10x30x9
XBER6200ZZ
Shielded Deep Groove Ball Bearing – Metric 10x30x9
Deep Groove Ball Bearings are the most common bearing type found in a wide variety of applications. Versatile and robust they are available in a wide range of sizes and options including seals, shields and special clearance for high speed applications.
The main types are:
Open – Bearing without seals or shields, suitable for applications where lubricant will constantly flow through them i.e. gearboxes.
Metal Shields – Bearings fitted with steel shields and lubricated for life.
Rubber Seals – Bearings fitted with steel reinforced rubber contact seals which provide a better seal but add friction so are unsuitable for high speed applications, lubricated for life.
Specs
Measurement Unit Metric
Inside Diameter 10.00mm
Outside Diameter 30.00mm
Width 9.00mm
Seals or Shields Metal Shields
Clearance Standard If the bearing selected is equipped with metal shields (ZZ), it has non-removable, no contact steel shield. These shields enable you to run the bearings at a higher temperature and since the inner race has no contact with the shield there is no impact on torque or speed. The downside to this type of enclosure is the lack of sealing protection from outside elements.
This bearing is sometimes marked with one of the following markings 6200-ZZ, 62002Z, 62002Z, 62002Z, 200KDD, 1200FF, 77200, 6200ZZ, 200SFF, 200PP, 77500, 6200ZZ, 6200ZZ, 62002Z, 6200ZZ The 6200-2RS and 6200-ZZ is a 10mm ball bearing that is found in many applications. The 6200-2RS ball bearing has two contact rubber seals one on each side of the ball bearing. The 6200-ZZ ball bearing has two non-contact metal shields one on each side of the ball bearing. If your application requires a 6200 ball bearing with only one seal or shield you can get this ball bearing and take one of the shields or seals off.
