Description
Switch PTO for Husqvarna 532154959 Hustler 77146 776476 John Deere MTD Murray 94927 Scag 463034
p/n: AAR9656
Description: Switch PTO Power Take off
It is an authentic part used with riding lawn tractors/mowers. This is the switch that allows user to engage blades. To stop mower blades, place attachment clutch control in the “DISENGAGED” position. One (1) plastic switch is included per order. Mechanical switches tend to break with time, eventually requiring replacement. This is standard 8 terminal black switch.
Replacing this switch is a simple task.
- Make sure to disconnect spark plug
- Once you gained access under the housing disconnect wires
- Remove old switch by pushing on side tabs
- Secure new PTO switch
- Reconnect wires and spark plug
- Test the unit
Replaces OEM p/n:
- Ariens: 21546196, 582107601
- AYP Poulan Weed Eater: 140404, 146283, 154959, 154963, 169416, 169417, 174651, 174652, 174653, 191231, 532174651, 582107601
- Bad Boy: 056-8058-00
- Bobcat Ransomes: 1985032
- Bunton: PL7994
- Bush Hog: 50018299
- Delta: 6201-303, 6204-303, 6205-131B, 6205-321
- Dixie Chopper: 6201-303
- Dixon: 539101768, 539120023, 539117238, 539129512, 5961
- Encore: 523030, 523031
- Ferris: 1722887, 22180, 5022180
- Great Dane: D38005
- Husqvarna: 532140404, 532154959, 532169417, 532174651, 532174652, 539101768, 582107601, 582107602
- Hustler: 771476, 776476
- John Deere: B1SC88
- Kees: 101768
- MTD: 725-07532
- Murray: 6201316, 6201316MA, 94927, 94927MA
- Scag: 463034, 481687, 483162, 483957, 485833
- Simplicity: 171348, 171348SM, 1714772, 1714772SM,1716332, 1716332SM, 1722887, 1722887SM, 5022180, 5022180SM
- Snapper: 1722887, 1722887SM, 3-5658, 35658, 5022180, 5022180SM, 7035658, 7035658YP
- Worldlawn: 4807005, 523031
- Wright: 52420003
- Yazoo: 101768, 539101768
Fits Models:
- Bad Boy: Lightning Z, 2007, with 52″, 60″ and 72″ deck; and ZT Elite series
- Great Dane: Chariot Sr. with 52″ and 61″ rear deck; and Super Surfer Frame with 48″, 52″ and 61″ deck
- Husqvarna: YTH1542XP, YTH1542XPG, YTH1848XP and YTH1848XPF; LZ with 52″, 60″ and 72″ deck
- Hustler: Super Z, 2002-2007, with 52″ 60″ and 72″ deck, excluding XR-7 deck drive units; FasTrak with 44″ and 52″ deck
- Scag: Cheetah, Freedom Z, Turf Tiger and Tiger Cat walk behinds
- Sears: most units
- Wright: Stander, 19729-26979, with 48″, 52″ and 61″ deck
Specs:
- Black knob
- Color of knob may vary by manufacture
- Manufactured by Delta Systems Inc.
- Push/pull
- Snap mount
- Ignition type: PTO
- No of Positions: 2
- No of Terminals: 8
- Bottom Left Corner terminal blank.
- Push – pull / snap mount.
- Replaces several switches with 4, 5 or 7 terminals.
Husky OEM Part.
